SlimeVR Trackers
You can also access our tutorial video!
SlimeVR is a community of people working to make the experience of being immersed in full-body virtual reality fun and reliable for everyone! SlimeVR has been hard at work adding features and support for a variety of chips and operating systems since early 2021!
None of OziVR could have been made without the constant support and positivity of the slimevr community! they have been incredibly open about their tracker scams and always willing to help and teach others how trackers work and any issues they have already sent there!
Introduction and Downloads
- Download the SlimeVR app from the website: OziVr.com.br/aplicativo
Configuring trackers
-PCVR
1
2
3
4
5
6
7
- Some information about the tracker numbers:
Ozi 1 - Foot
Ozi 2 - Ankle
Ozi 3 - Thigh
Ozi 4 - Waist
Ozi 5 - Chest
Ozi 6 - Elbows
Comments
It is extremely important that your Tracker is turned off when configuring it.
If you face any problems during this process go to the page Common Problems🇧🇷if the problem persists go to the page Support🇧🇷
- Connect Trackers
To connect your trackers to your Wi-Fi network (WI-FI 2.4ghz, Ozi doesn't support Wi-Fi 5ghz) use your Micro-USB cable connected to the Tracker, and then connect it to your computer.
After connecting it open the SlimeVr application, and then on the Wi-Fi tab in Setup Wizard. After that, enter your Wifi credentials.
After configuring all Trackers, leave them turned off on a flat surface.
Still under the surface bind them, leaving them still for 2 minutes, for self-calibration.
When they are all calibrated, wear them correctly on your body.
- For you to see all your trackers on steam vr click on Chest, Waist and legs in settings on SteamVR. If you have the OZI-6 click on Elbows.
Activate the Developer Mode, so you can configure each tracker for each body part, do the following steps:
- Move your Ozi and then you will see which Tracker is moving in the app, when you find it, Click on the tracker you are moving, and put the following settings:
Ozi-1 Right | FOOT-RIGHT
Ozi-1 Left | FOOT-LEFT
Ozi-2 Right | RIGHT_LOWER_LEG
Ozi-2 Left | LEFT_LOWER_LEG
Ozi-3 Right | RIGHT_UPPER_LEG
Ozi-3 Left |LEFT_UPPER_LEG
Ozi-4 | WAIST FRONT OR WAIST BACK
Ozi-5 | CHEST FRONT OR CHETST BACK
Ozi-6 Right | ELBOW-RIGHT
Ozi-6 Left | ELBOW-LEFT
Once you've set them up, log into SteamVR, and then you'll need to stand still for the calibration.
- How to calibrate
To calibrate, stand up straight, press the RESET button and stand still for 3 seconds. When you're done, you'll see your trackers on SteamVR.
- In case the Tracker is not going in the right direction
If your trackers are not moving in the direction you moved, the app has an option written “FRONT, LEFT, RIGHT and BACK”.
If your tracker is not going in the right direction and is in “BACK” select “FRONT”, after that you click on “RESET” and calibrate again.
Do this until your trackers are accurately tracking your body.
If when you sit or lie down your legs cross, place the OZI-3 trackers further in from your ankles.
If one is higher than the other when you lie down, this is a normal problem with any tracker.
8
Settings for VrChat Players
- Use IK Tweaks, select settings. You will see 3 icons, select the one that has the best tracking option for you.
Recommendations for better tracking
1
2
3
4
- For you to avoid drifts, you need to have downloaded the OVR ADVANCED SETTINGS.
It helps you to RESET your VR controller.
Tutorial available at: OziVr.com.br/tutorial
Have an internet Router/Receiver next to your PC in your gaming area.
Go to settings > tracker mechanics and enable smoothing and leave it at 60%
Go to Settings > FK Options and enable Ground Traversal and Slide Correction and leave it at 60%
common problems
Credits for:SlimeVR Docs
1
2
3
4
5
7
8
9
10
6
11
12
- Trackers going the wrong way?
Make sure your mounting orientation on the server is correct (you may have to lie on them for certain configurations).
If its only a few degrees off, shift your trackers in or out slightly, then reset them completely.
- Does your avatar float above the ground?
Increase your users real height in VRChat.
- Are your Foot Trackers on your avatar's knees?
This is a problem with current VRChat IK, use IKTweaks OR Beta VRChat IK, then select height scaling mode in settings.
- My knees are not bending
Make sure you have Knee Trackers above your knees and assigned as Leg Trackers.
Make sure your Ankle Trackers are set to Ankles and are on the ankles, not the feet.
Make sure VRChat is linking your feet to the Foot Trackers, not the Knee Trackers.
- Do your legs cross when sitting down?
Try mounting your Trackers on your knee further in.
Try to mount your Trackers knee higher on your thighs or lower on your knees, depending on your build.
Gauge with straight legs and a normal hip width (24-32) in body proportions.
- Do your hips move when you lift your legs?
Make sure your Waist Tracker is on your waist, above your hips.
- Are your Foot Trackers on your avatar's knees?
This is a problem with current VRChat IK, use IKTweaks OR Beta VRChat IK, then select height scaling mode in settings.
- Is your leg higher than the other?
Shift your Knee Trackers up a bit.
Try other mounts for your Knee Trackers.
- My Trackers are totally broken on SteamVR
Turn on the trackers on a flat surface and leave it still for 25 to 30 seconds for it to self-calibrate.
- Are your elbows (OZI-6) open in VRChat?
Calibrate with the arms curved further inwards in VRChat. The rotations of your elbows must match those of your avatar.
- My Trackers are not connecting in the Application
Make sure the trackers are connected to a 3.0 port on your computer, after that put your Wi-Fi network on a 2.4ghz internet mold/receiver. Enter uppercase and lowercase letters and spaces correctly🇧🇷Also disable your Windows Firewall and your anti-virus🇧🇷 If the problem persists, contact the Support🇧🇷
- My ping is high.
It is necessary to have a WI-FI Router near your computer and your Tracker. If you still insist, restart your computer, your internet connection and also close and open the application and you can also try cleaning your WI-FI cache.
- Access
Security Notices
1
2
3
4
Do not pass alcohol on the Trackers
Do not leave the Trackers exposed to high temperatures and exposed to the sun
Do not remove the warranty seal before the end of the term.
If you violate the warranty, it will no longer be valid and neither will the Online Support
Do not play while charging, it can damage the battery
Warranty does not cover battery failure.
Bracket and serial number
1
2
- Support contact
Contact us via serverdiscord
Website chat support (bottom right)
Email:support@ozivr.com
- If you have a problem with the trackers, also inform the serial number of the Tracker.
To see the tracker's serial number, look at the back of the Tracker.
